مسیریابی منطقه‌ای توان‌آگاه برای شبکه‌هایروی تراشه سه‌بعدی نیمه‌متصل
الموضوعات :
میترا معلم نیا
1
(دانشگاه علم و صنعت ايران)
هادی شهریار شاه حسینی
2
(دانشگاه علم و صنعت ایران)
الکلمات المفتاحية: شبکه روی تراشه, مسیریابی در شبکه, مدیریت انرژی, ارزیابی کارایی,
ملخص المقالة :
شبکه‌های روی تراشه،یک بستر ارتباطی کارآمد را برای برقراری ارتباط بین تعداد بالای هسته پردازشی در تراشه‌های مدرن امروز فراهم می‌کنند. با این حال کاهش ابعاد ترانزیستورها سبب شده تا مصرف توان ایستا به یکی از مسائل مهم در این شبکه‌ها تبدیلگردد. معمولاً از روش قطع تغذیه سیستم بر روی کانال‌های مجازی در زمان بیکاری‌شان برای کاهش توان مصرفی شبکه استفاده می‌شود؛ اما پراکندگی بار در سطح شبکه و عدم پیوستگی دوره بیکاری در کانال‌های مجازی باعث روشن و خاموش‌شدن متوالی این منابع می‌شود که سربار تأخیر و توان مصرفی را به دنبال دارد. این مسئله در شبکه‌های روی تراشه سه‌بعدی نیمه‌متصل که تعداد اتصالات عمودی‌شان محدود می‌باشد از اهمیت بیشتری برخوردار است. در این مقاله،یک الگوریتم مسیریابی برای شبکه‌های سه‌بعدی نیمه‌متصل ارائه می‌شود که با توزیع مناسب بسته‌ها، پراکندگی بار را در شبکه کاهش می‌دهد تا یک دوره بیکاری پیوسته در کانال‌های مجازی ایجاد کند. به این ترتیب می‌توان با بیشتر خاموش نگه داشتن آنها بهترین تأثیر را از روش قطع تغذیه سیستم در مدیریت توان مصرفی گرفت. این مسیریابی با تقسیم‌بندی شبکه به دو منطقه شمالی و جنوبی و ایجاد محدودیت در استفاده از آسانسورهای هر منطقه، سعی دارد که بسته‌ها را از مسیرهایی عبور دهد که اخیراً بیشتر استفاده شده‌اند تا دوره بیکاری را در منابع پرمصرف موجود در مسیرهای کم‌تردد افزایش دهد. نتایج شبیه‌سازی تحت شبیه‌سازBooksim نشان می‌دهند که مسیریابی پیشنهادی در مقایسه با مسیریابی‌های دیگر، توانسته 18% تا 30% بهبود در توان مصرفی شبکه ایجاد کند و عملکرد شبکه را نیز از نظر تأخیر تا 32% بهبود بخشد.
